Jib Crane

The wall mounted workstation jib crane is designed for efficient and flexible production scenarios. It adopts a compact structure and maximizes the release of floor space through wall mounted or ceiling-embedded installation. It is suitable for compact workstations such as laboratories, assembly lines, and precision machining. Its high-strength jib supports 360° rotation and multi-angle precise positioning. With servo drive and intelligent control system, it can easily achieve millimeter-level material grabbing and handling, and the load capacity covers light to ton-level workpieces.

Components of wall mounted jib crane

  ● Support structure: wall mounted mounting base or ceiling-embedded bracket, made of high-strength steel or aluminum alloy to ensure stable load-bearing.

  ● Rotating arm system: main arm and extension arm module, built-in precision bearings and rotating joints, support 360° horizontal rotation and multi-angle pitch adjustment.

  ● Drive system: according to the design, it can be divided into electric drive or manual operation system, which is used to control the rotation of the jib and the lifting and lowering of the hook.

  ● End effector: modular fixture interface (such as pneumatic grippers, vacuum suction cups, electromagnetic suction cups, etc.), adapted to different material grabbing needs.

  ● Safety protection device: overload protection sensor, mechanical limit switch, emergency stop button and anti-fall locking mechanism.

Advantages of wall mounted workstation jib crane

  ● It is wall mounted and does not occupy the ground area. It is suitable for workshops or working environments with small space, which helps to optimize the overall layout.

  ● The jib structure can cover a large working range, realize the rapid handling and dispatching of materials, and thus improve production efficiency.

  ● It can be directly installed on the existing wall or structure without additional ground foundation, with strong adaptability and easy transformation and expansion.

  ● The simple structure and fixed components make daily inspection and maintenance more convenient.

  ● Aluminum alloy, steel or composite materials are used to ensure the load-bearing capacity.

The wall mounted jib crane we produce is flexible in rotation and easy to operate. It is suitable for various industrial production environments, especially for clean rooms, precision assembly and small working areas. We can customize different specifications according to customer needs. Welcome to contact us for free design solutions and preferential prices!
